processor：Intel®8th/10th Whiskey lake-U&Coffeelake-U&Cometlake Processor
chipset：Intel® SOC
Display: Intel® UHD Graphics
memory：2*SO-DIMM DDR4 3200MHz Max 64GB
Display output：2*HDMI、1*DP (Support 3 display synchronous/asynchronous output)
storage：1*SATA3.0；1*M.2 Key M (Supports Sata&PCIe NVMe SSD adaptive)
USB:4*USB 3.0，3/5*USB 2.0
supports 4*COM232 (COM1 supports RS232/485 as an option)
On board 1/2 * RTL8111 gigabit network card
Expansion slot：1*M.2 Key E （Supports WiFi+Bluetooth extension）
Expansion slot：1*Mini PCIe (Supports Wifi+Bluetooth /4G expansion modules) 1*SIM card slot
| General | |
| CPU | Intel®8th/10th Whiskey lake-U&Coffeelake-U&Cometlake Processor |
| Chipset | Intel® SOC |
| Memory | 2*SO-DIMM DDR4 3200MHz Max 64GB |
| Storage | 1*SATA3.0 1*M.2 Key M (Supports Sata&PCIe NVMe SSD adaptive) |
| Expansion Interface | 1*M.2 Key E （Supports WiFi+Bluetooth extension） 1*Mini PCIe (Supports Wifi+Bluetooth /4G expansion modules) 1*SIM card slot |
| BIOS | AMI BIOS |
| System | Windows 10/11 32bit/64bit/Linux |
| I/O Interface | |
| Ethernet | 1/2*Realtek® RTL8111 1Gbps Ethernet Controller，RJ45 |
| Serial | 4*COM232 (COM1 supports RS232/485 as an option) |
| USB | 4*USB 3.0，3/5*USB 2.0 |
| Audio | Onboard audio decoding controller ALC897 + NS4251 default power amplifier support 3 w @ 4 Ω; 1.7W@8Ω max |
| Others | 1*4PIN ATX Header 1*TPM Header 1*CPU FAN Header 1*R_USB Header（Extensible 1*USB2.0） 1*GPIO Header 1*SPEAKER Header 1*F_PANEL Header 1*JAT Header 1*SATA interface 1*SATA_PWR Header 4*COM232 Header |
| Display | |
| Display Interface | 2*HDMI、1*DP (Support 3 display synchronous/asynchronous output) |
| Mechanical & Environment | |
| Dimension | 121mmX121mm |
| Power Input | DC 12V-19V input power supply |
| Temperature | Operation: 0℃~60℃, Storage: -20℃~75℃ |
| Relative Humidity | 0% ~ 95%, non-condensing |
Embedded motherboard is generally understood as the CPU board embedded in the device for contro...
Both industrial control computers and computers belong to the category of computers, and their m...
X86 embedded motherboard is a type of embedded motherboard, characterized by its small size and...
