Home > Products > Mini PC > NANO Mini Pc
◆Intel® 12/13th CoreTM i3/i5/i7 or Celeron®Processor
◆Supports 2*SO-DIMM, DDR5 4800MHz/5200MHz (13th generation) with a maximum capacity of 64GB
◆Supports HDMI, DP, and 1*Type-C display. It can support synchronous/asynchronous output of three displays. 1 * M.2 Key M (2280mm, supporting SATA 3.0 & PCIe X4 adaptive)
◆1*M.2 Key E (2230mm, supports Wifi+Bluetooth, supports WiFi 6 and CNVI)
◆1*M.2 Key B (3042/52mm, supports 4G/5G expansion) 1*Nano SIM
◆Built-in 4*Intel i226-V network card, supports 4 network ports and 4 POE
◆3*USB3.2 (10Gbit/s), 4*USB2.0 (480Mb/s),
◆1*Type-C USB 3.2 (10Gbit/s)
◆Supports 12V@60W power adapter supply; (Optional POE supply is available, requires 12V@90W power adapter)
Processor | Intel® 12/13th CoreTM i3/i5/i7 or Celeron®Processor | ||
BIOS | AMI supports functions such as write protection, network wake-up,power-on startup, timed startup, and remote watchdog. | ||
Memory | Capacity | 2 x SO-DIMM memory slots, supporting DDR5 4800MHz/5200MHz (13th generation), maximum support for expansion of 64GB | |
Storage | Port | 1 * M.2 Key M (2280mm, supporting SATA 3.0 & PCIe X4 adaptive) | |
Display | Intel® Iris® Xe Graphics 1 x HDMI 1 x DP 1 x Type-C Display | ||
Network | Wired | 4 x Intel i226-V network card (with built-in RJ45 port) | |
Wireless | 1 * M.2 Key B (3042/52mm, supporting 4G/5G expansion) 1 * Nano SIM | ||
Post-processed IO | USB | 4 x USB2.0 port | |
Net Opening | 4 x RJ45 | ||
DC | 1 x DC power outlet | ||
Antenna | 4 x Antenna holes | ||
Front-end I/O | USB | 3 x USB3.2 1 x Type-C USB 3.2 | |
COM | 1 x DB9 COM | ||
Button | 1 x Power Button | ||
Power supply | Import | Supports 12V @ 60W power adapter for power supply; (Optional POE power supply is available, requires 12V @ 90W power adapter) | |
Watchdog | Function | Restart the system after a crash | |
Interval | 1 ~ 65535sec | ||
Mini Pc size | 167*125*59mm | ||
Operating system | Versions | Windows 10/11 32bit/64bit/Linux | |
Work environment | Temperature | Working temperature: 0°C ~ 60°C Storage temperature: -20~75°C | |
Humidity | 0% - 90% No condensation | ||
