processor：Intel® 7th/6th（Kabylake/Skylake-H)Mobile Processor
chipset：Intel 100 series
Display: Intel® HD Graphics
memory：2*SO-DIMM，DDR4 2400 MHz Max 32GB
Display output：HDMI、VGA、EDP2、LVDS/EDP1 (Support 3 display synchronous/asynchronous output)
storage：2*SATA3.0；1*M.2 Key M (Supports Nvme&SATA SSD)
USB:4/6*USB3.0；4*USB2.0
supports 6*COM232 （COM2 supports RS232/485 as an option）
On board 1/2* RTL8111 gigabit network card
Expansion slot：1*M.2 Key A （Supports WiFi+Bluetooth Expandable）
Expansion slot：1*M.2 Key B (for 3G, 4G expansion or SATA SSD, 5G optional)
| General | |
| CPU | Intel® 7th/6th（Kabylake/Skylake-H)Mobile Processor |
| Chipset | Intel 100 series |
| Memory | 2*SO-DIMM，DDR4 2400 MHz Max 32GB |
| Storage | 2*SATA3.0 1*M.2 Key M (Supports Nvme&SATA SSD) |
| Expansion Interface | 1*M.2 Key E （Supports WiFi+Bluetooth extension） 1*M.2 Key B (for 3G, 4G expansion or SATA SSD, 5G optional) 1*SIM card slot |
| BIOS | AMI BIOS |
| System | Windows 7/10/11 32bit/64bit/Linux |
| I/O Interface | |
| Ethernet | 1/2*Realtek® RTL8111 1Gbps Ethernet Controller，RJ45 |
| Serial | 6*COM232 （COM2 supports RS232/485 as an option） |
| USB | 4/6*USB 3.0, 4*USB 2.0 |
| Audio | Onboard audio decoding controller ALC897 + NS4251 default power amplifier support 3 w @ 4 Ω; 1.7W@8Ω max |
| Others | 1*ATX Header 1*VGA Header 2*F_USB2.0 Header（Extensible 4*USB2.0） 1*F_USB3.0 Header（Extensible 2*USB3.0） 1*GPIO Header 6*COM Header 2*SATA3.0 interface 2*SATA_PWR Header 1*F_PANEL Header 1*F_AUDIO Header 1*SPEAKER Header 1*DEBUG Header 1*PS/2 Header 1*LPT Header 1*JAT1 Header 1*LVDS Header 1*EDP Header 1*LCTL1 Header 1*INVCN1 Header 1*SYSFAN Header 1*CFAN Header |
| Display | |
| Display Interface | HDMI、VGA、EDP2、LVDS/EDP1 (Support 3 display synchronous/asynchronous output) |
| Mechanical & Environment | |
| Dimension | 170X170MM |
| Power Input | DC 12V-19V input power supply or ATX4pin power supply |
| Temperature | Operation: 0℃~60℃, Storage: -20℃~75℃ |
| Relative Humidity | 0% ~ 95%, non-condensing |
Embedded motherboard is generally understood as the CPU board embedded in the device for contro...
Both industrial control computers and computers belong to the category of computers, and their m...
X86 embedded motherboard is a type of embedded motherboard, characterized by its small size and...
